Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen

    Buy cheap Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen from wholesalers

    Buy cheap Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen from wholesalers
    • Buy cheap Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen from wholesalers
    • Buy cheap Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen from wholesalers
    • Buy cheap Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen from wholesalers

    Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen

    Ask Lasest Price
    Brand Name : XGCLED
    Model Number : P15.625 outdoor mesh led screen
    Price : USD$2200~3000/square meter
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000 square meter per month
    Delivery Time : 7-20days
    • Product Details
    • Company Profile

    Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen

    The newest waterproof indoor P15.625 curtain / mesh/ transparent advertising display


    Advantages :


    1) No Escape tool design , Screen environment mostly glass building in case of fire , escape and rescue are very urgent and important ,

    P15.625 outdoor screen tool-free disassembly function screen rear side of two seconds , especially respect for life and fully meet fire safety requirements .


    2) Unique within the industry , ultra-light weight : Unit box weighs only 7.45kg (500mmX1000mm), the project is only 1500KGS screen boby

    weight thus reducing the building to support the weight of the body on the screen , minimize security risks.


    3) Standardized installation framework ( standard frame size 2000mm width X1000mm height ), small on -site construction difficulty , high precision , fast efficiency . The measure , the industry faster than 3~5 times , greatly reducing the body of the screen frame and fixed installation


    time, substantial saving in installation costs .


    4) The screen is fixed to the boby frame fixed frimware process is simple , easy to operate , completely within the industry complex and time-consuming step shortcomings .


    5) Ultra power -saving design : each squared average power consumption control at about 150W , than peers of similar products saving more

    than 50% each year for the owner saving about eight million (100 square meter , runs daily from 8:00 am to 22:00 , ie 14 hours calculated)


    6) The dual power backup design , display body control card power supply and separate power supply , reducing power interference between the two improve quality screen body stablity .


    Technical parameter


    1) Module specification


    NoItemParameter
    1Pixel pitch15.625MM
    2Module size1000*500MM
    3Module weight0.3kg
    4LED TypeDIP RGB
    5Pixel Config1R1G1B
    6Total Pixels64*32Pixel
    7Brightness≥10,000cd/
    8Drive modeConstant current
    9View angle160°/140°
    10ApplicationOutdoor

    2) Cabinet specification


    NoItemParameter
    1Pixel density4,096.00dots/
    2Cabinet size1000*500 mm
    3Max power consumption800W/
    4Average power consumption300W/
    5Weight7kg
    6Input voltageAC110/220V
    7Cabinet materialAlluminium
    8LockYes
    9ConnectorsYes
    10Stand supporterNo
    11Power supply brandMeanwell
    12ICMBI5124


    3) Screen specification


    NoItemParameter
    1Screen sizeCustomized size
    2Cabinet quantitycustomized
    3Best viewing distance>2m
    4Operation temp-20~60
    5Operation Humidity10%90%
    6Control PCOffered by yourself
    7Refresh rate≥1920Hz or 3840Hz
    8Frame rate60 frame/s
    9Gray scale>8192grade
    10Colors of display1.07 billion
    11Brightness adjustmentBrightness adjustment by software
    12Video SignalPAL/NTSC
    13MTBF>5,000 hours
    14Life span>100,000 hours
    15Drive modestatic, constant current
    16Operation systemWindows Series
    17Display function file formatsAVI, MOV, MPG, DAT, VOB
    18Information sourceMany kinds of signal access: can input TV signals ,DVD signals , DVI, S-VIDEO, RGB, VGA, and so on.


    How to select a LED display


    1) Location -indoor , outdoor or semi-outdoor

    Location is the most important factors for selecting the correct LED display . Different type of location such as rooftop , large billboard and stage backdrops or requires front access for serving will require different led cabinets and modules .


    2) Size , shape and pitch


    Size :Once you have measured the height , width and longth of the space and availability , then you want to make sure the selected LED size ( and number of cabinet , height , width & depth ) can be accommodated .


    3)Our company believes that high quality products help us to develop long-term customers .


    The solutions that suit the customer is the best ,the best and in-time after-sales service will be provided to save client ' miantain cost , time and energy .

    Quality Outdoor Waterproof MBI5124 1R1G1B P15.625 LED Mesh Screen for sale
