    Flexible Transparent P3.91 P7.81 Led Mesh Flexible Curtain Screen

    Ask Lasest Price
    Brand Name : XGC
    Model Number : P3.91-7.81
    Certification : CE, RoHs, FCC, CCC
    Price : USD400--USD1000 /㎡
    Payment Terms : T/T、, Western Union、L/C、, D/A, MoneyGram
    Supply Ability : 3000㎡ per month.
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    Flexible Transparent P3.91 P7.81 Led Mesh Flexible Curtain Screen

    Flexible Transparent P3.91 P7.81 Led Mesh Flexible Curtain Screen


    P3.91 P7.81 Transparent Led Mesh Flexible Curtain Screen Shenzhen Factory Price High Permeability Rate


    Product Features


    1. Light weight: The aluminum die-casting technology we adopt is about 10kg which is convenient for assembly and disassembly.


    2.Hight refresh rate: more than 1920Hz refresh rate to ensure the picture wrinkle-less, line-less and stable.


    3. Low brightness and High gray scale:16Bit gray scale to bring excellent performance when brightness is reduced to 25%, and it can bring perfect display performance with no flckering.


    4. Easy to install: Don't need to worry about the installation, it is easy, because of the design of the Die casting cabinet, Just like building block


    5. High IP Grade: The IP65 insures the reliable operation in different enrionment, and it is more safe.


    6. High brightness: For the outdoor transparent LED display 2500-5500cd/sqm,indoor advertising LED mesh screen 1200cd/sqm.


    Technical parameter for P3.91 Transparent LED Mesh Display


    Module Specifications
    1Pixel Pitch3.91-7.81mm
    2LED TypeSMD1921 (Anti-UV)
    3Driving ICICN/ MBI
    4LED PackageNationstar

    Cabinet Specification

    1Cabinet Size500*1000mm
    2Cabinet Resolution128*256pixels
    3Module Qty.1x2pcs
    4Cabinet MaterialAluminum Alloy
    5Cabinet Weight10Kg

    Screen Parameter

    1Screen Sizecostomized size
    2Brightness≥1200cd/m2
    3Scanning Mode1/16scan
    4Viewing AngleH:160°;V:160°
    5Viewing Distance>4m
    6Gray Level16 Bit
    7Refresh Frequency≥1920 Hz
    8Power InputAC 110-240V
    9Power ConsumptionMax: 600W/ Average: 200W/
    10MTBF--hours>10,000 hours
    11Life--hours≥100,000 hours
    12IP GradeIP40
    13Operating Temperature20℃~+60or40℃~+60
    14Storage Humidity10%-85%RH
    15Control SystemNovastar
    16Operating SystemWindows10/2000/NT/XP
    17Power Supply5V 40A 200W /5V60A 300W
    18Maintance AccessBack service
    19Installation MethodBack Frame /Hoisting /Inner Arc Installation
    20Display File FormatsAVI, MOV, MPG, DAT...

    Regular Package:




    FAQ

    1.How long could I receive the inquiry reply?

    A:You will get our reply within 24 hours.


    2.What kind of led display do you offer?

    A:Different product offers different time warranty, but we offer at least 2-5years warranty.


    3.How is the after sales service?

    A:We have a professional after-sales team, we also have a service hot-line dealing with your feedback. We also offer 24-hour online service to help you solving problems


    4.How long will it take to deliver goods?

    A:We will start preparing goods when we get your deposit receipt. The product will be ready soonest when it's in production.


    5. What is the brightness, viewing angle and wave length of led chip?

    A: Luminous Intensity is equal to the amount of luminous flux emitted into a very small solid angle at a defined angular orientation from the light source. The measurement for luminous intensity is the candela. Symbol is Iv. Viewing Angle is the total cone angle in degrees encompassing the central, high luminous intensity portion of the LED beam from the on-axis peak to the off-axis point where the LED intensity is 50% of the on-axis intensity. This off-axis point is known as theta one-half ( 1/2). Two times 1/2 is the LEDs' full viewing angle; however, light is visible beyond the1/2 point. Wavelength is the distance between two points of corresponding phase and is equal to waveform velocity divided by frequency. It defines what color human eyes could recognize.


    6. What is the dominant wavelength? Please specify the range of wavelength in red/ blue/ green color respectively.
    A: Dominant wavelength is defined as the best range of wavelength showing the most natural color recognized by human eyes. Researches indicate that fixed colors with wavelength of 620-630nm (red), 520-530nm (green) and 460-470nm (blue), in fact mixed in a particular proportion, can get the pure white. That is, in display field, people use luminous materials with above wavelength to make "compounded" white more natural.In order to get a good balance white led display, we specify the led colors with wavelength within 4nm for each color.
