    Front Maintenance Digital Counter IP65 P4 Stadium LED Screen

    Ask Lasest Price
    Brand Name : XGCLED
    Model Number : P4 LED stadium digital counter display
    Price : $890~1288USD/㎡
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 5000 square meter per month
    Delivery Time : 7-20days
    • Product Details
    • Company Profile

    Front Maintenance Digital Counter IP65 P4 Stadium LED Screen

    Cost -effective front maintenance stadium screen LED digital counter display


    Features:


    1) Power supply installed on the back of the cabinet door , good cooling function.


    2) Light weight only 20kg for cabinet


    3) Fast lock design , good rental hanging solution , and more accurate and easy to handle ,

    make it mininum gaps beween cabinet .


    4) High refresh rate ,good waterproof.


    Technical parameter


    Module Specification
    1Pixel Pitch4mm
    2Led TypeSMD2525
    3Module Size256x128mm
    4Module Resolution64x32 pixels
    5Driving ICMBI5124
    6LED lampKinglight
    Cabinet Specification
    1Cabinet Size768x768mm
    2Cabinet Resolution192x192 pixels
    3Module Qty.3x6pcs
    4Cabinet MaterialsDie-casting aluminum
    5Cabinet Weight< 30Kg
    Screen Parameters
    1Screen Size3.84X2.304m
    2Screen Resolution960x512
    3Cabinet Qty.15
    4Brightness5500 cd/m2
    5Scanning Mode1/8scan
    6Viewing AngleH:140°;V:140°
    7Viewing Distance>4m
    8Gray Level16 Bit
    9Refresh Frequency480-1920 Hz
    10Power InputAC 220-240V
    11Power ComsuptionMax: 800W/ Average: 250W/
    12MTBF--hours>10,000 hours
    13Life--hours≥100,000 hours
    14IP GradeIP65
    15Operating Temperature-30~ 60
    16Storage Humidity10~90RH
    17Control SyetemNovastar
    18Operating SystemWindows98/2000/NT/XP
    19Power SupplyG-ENERGY
    20Maintance AccessBack service

    FAQ


    Q1: Can I have a sample order for this products?


    Yes , We welcome sample order to test and check quality .


    Q2: What about the lead time ?


    A2: Production time needs about 15 workingdays for order quality more than 6sqm


    Q3: Do you have any MOQ limit for LED screen order ?


    A3: Low MOQ 1 pcs for sample checking is availalbe and normal order's MOQ is 6 pcs cabinet .


    Q4: How do you ship the goods and how long does it take to arrive?


    By express is the fastest but most expensive . By airplan also need about 7 days , middle cost .

    By sea is the most economic but will take 20-30days transit time .


    Small order Express is a good solution , Big order always by sea.


    Q5: How to proceed an order for LED screen?


    A5: Firstly let us know your requirements or application .


    Secondly we quote according to your requirement or our suggestions.


    Thirdly customer confirms the samples and places deposit for formal order.


    Fourthly we arrange the production
